Busduct overheating monitoring
【Figure: Busduct overheating monitoring - Sample capture】
【Figure: Busduct overheating monitoring - Case studies】
B
usduct type is it is easy to transmission of large amounts of electric current in the conductor and the save installation space by Busbar form, and maintenance is convenient to use a lot of large buildings.
Bustuct stable on its own and can manage power distribution equipment safer by incorporating an optical temperature monitoring system (DTS) facility.
The use of power facilities grows, if you are increasing the amount of current applied to the Busduct especially vulnerable to excessive heat caused by the bottleneck of current is generated, install the DTS because it is very difficult to find the weak spots If you watch the Bustuct can be found just overheated areas, and prevent accidents.
In fact, cases of from 'L Company’ property damage in the billions of prevention by preventing accidents caused by overheating Busduct.
【Figure: Sample of fiber optic cable laying】
We used the DTS DMS system is based on a lot of field experience with software development, system installation and support from the whole process to operate.
In particular, user-friendly 3D screen and easy-to-use interface to provide the best solution as it detects an abnormal position, as well as allows users to operate easily and fix the problem.
Also excellent compatibility to enable Multi Vendor DTS Interface, and also designed to be easily linked to other systems.
- Applicable equipment :
Busduct as 600V 1000A ~ 6000A, 24kV - 4000A
